BackMatrix49 Pro LED-Modul, 49 LEDs, 29x29cm, 24V, 3000K warmweiß, 2090lm 52794

BackMatrix49 Pro LED module, 49 LEDs, 29x29cm, 24V

5-year warranty, no cooling required

High efficiency Nichia 757 LEDs
Impressive 137lm/W efficiency
Optimised for advertising & luminous ceilings
No cooling required

5-year warranty, no cooling required

49 Nichia 757 LEDs
Efficiency of 137lm/W
Optimal for advertising and luminous ceilings

$33.00 - $33.00

$33.00

$33.00 - $33.00

$33.00

Availability:

in stock, ready to be shipped

Availability:

Sold out

Quantity

Shipping and price information

13,90€ to UK and within the EU.
All countries/shipping rates.

Taxes and duties may apply outside the EU.

Prices incl. VAT and plus shipping. Comparison prices and discounts refer to the manufacturer's recommended retail price.

Payable with PayPal, ApplePay, AmazonPay, Mastercard, Visa, SOFORT

Accessories - Editorially selected

Lay-up tool for BackMatrix

now

$7.00 $10.00

View product

Meanwell HLG 24V, Netzteil, HLG-150H-24B (24V - 150W) 95189

Meanwell HLG 24V, power supply

from

$39.00

View product

Zuleitung, Querschnitt 2x 0,75mm², 5m, PVC 37592

Cable, cross section 2x 0.75mm², 5m, PVC

$4.00

View product

Dimmer für LEDs und LED Module (PWM) mit Drehregler 95019

Dimmer for LEDs and LED modules (PWM) with rotary control

$14.00

View product

BackMatrix49 Pro LED module: top performance from LUMITRONIX

The BackMatrix49 Pro LED module is an unparalleled product in terms of performance, efficiency and flexibility. Equipped with 49 Nichia 757 LEDs, it delivers a remarkable efficiency of up to 137lm/W and a luminous flux of up to 2090lm. The module offers many unique features, including solderless connection and adjustable brightness. Ideal for promotional material and luminous ceiling designs

The BackMatrix49 Pro technology: A class of its own

The BackMatrix49 Pro LED module sets new standards in LED lighting technology. With its uniform and homogeneous illumination, it ensures optimally illuminated surfaces, regardless of the application area. Offers easy handling thanks to its solderless connection system and convinces with an impressive service life, which is underlined by a 5-year warranty.

Areas of application: Large and small

From large-scale illuminated ceilings to radiant billboards - the BackMatrix49 Pro LED module opens up a wide range of possible applications. At the same time, it can also be used for smaller lighting projects, such as light boxes or advertising signs.

Features of the BackMatrix49 Pro LED module

LED technology: Equipped with Nichia 757 LEDs
High efficiency: Up to 137lm/W
Warranty: 5 years warranty
Optimised: Ideal for advertising and luminous ceilings
Flexible connection: Solderless connection possible with insulation displacement connectors
Cooling: No additional cooling required
Adjustable brightness: Onboard brightness adjustment with three levels
Even binning: Uniform white light due to Nichia binning
Dimensions: Compact with dimensions: 290x290x7mm

LUMITRONIX: The makers behind BackMatrix49 Pro

Known for industry-leading expertise and high-quality production lines, LUMITRONIX has been synonymous with outstanding LED lighting solutions for 20 years. Produced in Germany, our LED modules not only offer outstanding performance but also a long service life - a positive contribution to ecological sustainability. With our offerings on leds.de, we aim to inspire and supply both end users and micro-enterprises.

FAQ about the BackMatrix49 Pro LED module

Does the BackMatrix49 Pro LED module need additional cooling?
No, the module can be operated without additional cooling.

How is the BackMatrix49 Pro LED module connected?
You can use a solderless connection through insulation displacement connectors or attach the connecting cable to the prepared solder pads.

Can the brightness of the BackMatrix49 Pro LED module be adjusted?
Yes, the brightness can be adjusted in three steps via a switch on the module.

Technical Details
SKU	52794
Brand	LUMITRONIX
Energy efficiency class	A++
Light colour	Warm white
Life cycle (h)	60000 h
Manufacturer code	52794
Efficiency (lm/W)	125 (lm/W)
Luminous flux (lm)	2090 (lm)
Color temperature (K)	3000 (K)
CRI (Ra)	80
Power (W)	16.8 (W)
Voltage (V)	24.0 (V)
Electric Current (mA)	700 (mA)
GTIN	4260127455503
Size (L x W x H)	29 cm x 29 cm x 0.71 cm
Weight	0.293 kg
Categories Nr. 1 in BackMatrix LED Modules Nr. 8 in LED Modules Nr. 8 in LED Strips & Modules Nr. 2 in Matrix LED modules Nr. 5 in Produkte mit 10 Jahre Garantie
Data sheet BackMatrix 49 Professional, 24V (PDF)

Technical Details
SKU	36740
Brand	LUMITRONIX
Added	30.06.2021
Energy efficiency class	A++
Light colour	neutral white
Life cycle (h)	60000 h
Manufacturer code	36740
Efficiency (lm/W)	130 (lm/W)
Luminous flux (lm)	2180 (lm)
Color temperature (K)	4000 (K)
CRI (Ra)	80
Power (W)	16.8 (W)
Voltage (V)	24.0 (V)
Electric Current (mA)	700 (mA)
GTIN	4062986002337
Size (L x W x H)	29 cm x 29 cm x 0.71 cm
Weight	0.297 kg
Categories Nr. 1 in BackMatrix LED Modules Nr. 8 in LED Modules Nr. 8 in LED Strips & Modules Nr. 2 in Matrix LED modules Nr. 5 in Produkte mit 10 Jahre Garantie
Data sheet BackMatrix49 Pro LED-Modul, neutral white (4000K), 2180lm, 49 LEDs, 29x29cm, 24V (PDF)
