Cree XHP50 SMD-LED, 1120lm, 6500K, Cree XHP50 SMD-LED, mit Starplatine, 1120lm, 6500K 68483

Cree XHP50 SMD LED, 1120lm, 6500K

Cree

New SC5 technology: Higher lumen density

  • Applicable up to 3000mA (6V) / 1500mA (12V)
  • Efficient 85° binning
  • Minimum thermal resistance: 1.2°C/W
  • Extended lifetime over high operating temperatures

Powerful LED with 1120 lumen and 6500K

  • Cree XHP50 SMD-LED technology
  • High light output of 1120lm
  • Colour temperature of 6500K
  • Ideal for mini boards
$5.00 - $13.00
$13.00
$5.00 - $13.00
$13.00
Availability:
in stock, ready to be shipped
Availability:
Sold out
Shipping and price information

13,90€ to UK and within the EU.
All countries/shipping rates.

Taxes and duties may apply outside the EU.

Prices incl. VAT and plus shipping. Comparison prices and discounts refer to the manufacturer's recommended retail price.

Payable with PayPal, ApplePay, AmazonPay, Mastercard, Visa, SOFORT

Accessories - Editorially selected

Discover more highlights from Cree...

  • Cree XP-G3 S5 SMD-LED, 172lm, 6000K, Mit Starplatine pic2 68499
    Cree XP-G3 S5 SMD-LED, 172lm, 6000K, ohne Platine 68498

    Cree XP-G3 S5 SMD LED, 172lm, 6000K

    $2.00 - $4.00
    $2.00 - $4.00
    $2.00 - $4.00
    $2.00
    in stock

    Cree's XLamp XP-G3 LEDs are the most efficient and reliable LEDs in the XP-G platform. These LEDs meet the high requirements of the DLC rating for...

    View full details
    $2.00 - $4.00
    $2.00 - $4.00
    $2.00 - $4.00
    $2.00
  • Cree XHP70 SMD-LED, mit Starplatine, 1710lm, 6500K 68478

    Cree XHP70 SMD LED, with star board, 1710lm, 6500K

    $15.00 - $15.00
    $15.00
    $15.00 - $15.00
    $15.00
    in stock

    Thanks to the new SC5 technology platform, the Cree XLamps XHP50 and XHP70 set new standards for lumen density, reliability and for a radical reduc...

    View full details
    $15.00 - $15.00
    $15.00
    $15.00 - $15.00
    $15.00
  • Cree CXA1304 COB-LED, CRI95, 317lm, 3000K 68550

    Cree CXA1304 COB LED, CRI95

    $2.00 - $3.00
    $2.00 - $3.00
    $2.00 - $3.00
    $2.00
    in stock

    With the CXA1304, Cree is expanding the series in the lighting class category with another highly efficient array with enormous luminous intensity...

    View full details
    $2.00 - $3.00
    $2.00 - $3.00
    $2.00 - $3.00
    $2.00
  • Cree CXA1830 COB-LED, CRI95, 2735lm, 3000K 68554

    Cree CXA1830 COB LED, CRI95

    $6.00 - $10.00
    $6.00 - $10.00
    $6.00 - $10.00
    $6.00
    In stock

    With the CXA1830, Cree is expanding the series in the lighting class category with another highly efficient array with enormous luminous intensity...

    View full details
    $6.00 - $10.00
    $6.00 - $10.00
    $6.00 - $10.00
    $6.00
  • Cree MK-R SMD-LED, 970lm, 6200K, CRI 65 pic2
    Cree MK-R SMD-LED, 970lm, 6200K, CRI 65, Cree MK-R SMD-LED mit 12x12mm Platine, 1040lm, 6200K, CRI 60 68652

    Cree MK-R SMD LED, 970lm, 6200K, CRI 65

    $14.00 - $14.00
    $14.00
    $14.00 - $14.00
    $14.00
    in stock

    In 2011, Cree brought an LED onto the market that broke through the 200 lm/W mark for the first time under laboratory conditions. With the MK-R LED...

    View full details
    $14.00 - $14.00
    $14.00
    $14.00 - $14.00
    $14.00
  • Cree XM-L 2 U2 SMD-LED, Mit 10x10mm Platine, 300lm, 6500K, CRI 60 pic2 68633
    Cree XM-L 2 U2 SMD-LED, Mit Starplatine, 300lm, 6200K, CRI 65 68632

    Cree XM-L 2 U2 SMD LED

    $8.00 - $8.00
    $8.00
    $8.00 - $8.00
    $8.00
    in stock

    The Cree XM-L LED series is the industry's brightest LED class. Now also available in the entire white spectrum. The XM-L is 20% more efficient t...

    View full details
    $8.00 - $8.00
    $8.00
    $8.00 - $8.00
    $8.00
  • Cree XHP50 SMD-LED, 2700K, CRI 80, 840lm, ohne Platine pic2 68484
    Cree XHP50 SMD-LED, 2700K, CRI 80, 840lm, mit Starplatine 68485

    Cree XHP50 SMD LED, 2700K, CRI 80

    $4.00 - $11.00
    $4.00 - $11.00
    $4.00 - $11.00
    $4.00
    in stock

    Thanks to the new SC5 technology platform, the Cree XLamps XHP50 and XHP70 set new standards for lumen density, reliability and for a radical reduc...

    View full details
    $4.00 - $11.00
    $4.00 - $11.00
    $4.00 - $11.00
    $4.00
  • Cree CXA1512 COB-LED, 1099lm, 2700K, CRI 90 68556

    Cree CXA1512 COB LED, 1099lm, 2700K, CRI 90

    $4.00 - $4.00
    $4.00
    $4.00 - $4.00
    $4.00
    in stock

    With the CXA1512, Cree is expanding the series in the lighting class category with another highly efficient array with enormous luminous intensity ...

    View full details
    $4.00 - $4.00
    $4.00
    $4.00 - $4.00
    $4.00
  • Cree XP-E2 SMD-LED, 122lm, grün, Mit Starplatine pic2 68190
    Cree XP-E2 SMD-LED, 122lm, grün, Mit 10x10mm Platine 68189

    Cree XP-E2 SMD LED, 122lm, green

    $4.00 - $5.00
    $4.00 - $5.00
    $4.00 - $5.00
    $4.00
    in stock

    With its 3.45mm x 3.45mm footprint, the XP series is one of the new micro high-power LEDs. This type of LED package is increasingly establishing it...

    View full details
    $4.00 - $5.00
    $4.00 - $5.00
    $4.00 - $5.00
    $4.00
  • Cree XP-E2 SMD-LED, 45lm, blau, Mit Starplatine pic2 68186
    Cree XP-E2 SMD-LED, 45lm, blau, Mit 10x10mm Platine 68185

    Cree XP-E2 SMD LED, 45lm, blue

    $4.00 - $4.00
    $4.00
    $4.00 - $4.00
    $4.00
    in stock

    With its 3.45mm x 3.45mm footprint, the XP series is one of the new micro high-power LEDs. This type of LED package is increasingly establishing it...

    View full details
    $4.00 - $4.00
    $4.00
    $4.00 - $4.00
    $4.00
  • Cree XP-E2 SMD-LED, rot, Mit Starplatine, 73,9lm pic2 68198
    Cree XP-E2 SMD-LED, rot, Mit 10x10mm Platine, 73,9lm 68197

    Cree XP-E2 SMD LED, red

    $2.00 - $4.00
    $2.00 - $4.00
    $2.00 - $4.00
    $2.00
    in stock

    With its 3.45mm x 3.45mm footprint, the XP series is one of the new micro high-power LEDs. This type of LED package is increasingly establishing it...

    View full details
    $2.00 - $4.00
    $2.00 - $4.00
    $2.00 - $4.00
    $2.00
  • Cree XP-G3 R5 SMD-LED, 139lm, 2700K, Cree XP-G3 R5 SMD-LED, mit Starplatine, 139lm, 2700K 68495

    Cree XP-G3 R5 SMD LED, 139lm, 2700K

    $3.00 - $3.00
    $3.00
    $3.00 - $3.00
    $3.00
    in stock

    Cree's XLamp XP-G3 LEDs are the most efficient and reliable LEDs in the XP-G platform. These LEDs meet the high requirements of the DLC rating for ...

    View full details
    $3.00 - $3.00
    $3.00
    $3.00 - $3.00
    $3.00
  • Cree XP-E2 SMD-LED, 550mW, 450nm, royalblau, Mit 10x10mm Platine pic2 68181
    Cree XP-E2 SMD-LED, 550mW, 450nm, royalblau, Ohne Platine 68180

    Cree XP-E2 SMD LED, 550mW, 450nm, royal blue

    $2.00 - $3.00
    $2.00 - $3.00
    $2.00 - $3.00
    $2.00
    in stock

    With its 3.45mm x 3.45mm footprint, the XP series is one of the new micro high-power LEDs. This type of LED package is increasingly establishing it...

    View full details
    $2.00 - $3.00
    $2.00 - $3.00
    $2.00 - $3.00
    $2.00
  • Cree XHP50 SMD-LED, 1120lm, 6500K pic2 68482
    Cree XHP50 SMD-LED, 1120lm, 6500K, Cree XHP50 SMD-LED, mit Starplatine, 1120lm, 6500K 68483

    Cree XHP50 SMD LED, 1120lm, 6500K

    $5.00 - $13.00
    $5.00 - $13.00
    $5.00 - $13.00
    $5.00
    in stock

    Thanks to the new SC5 technology platform, the Cree XLamps XHP50 and XHP70 set new standards for lumen density, reliability and for a radical reduc...

    View full details
    $5.00 - $13.00
    $5.00 - $13.00
    $5.00 - $13.00
    $5.00
  • Cree XP-L V5 SMD-LED, CRI60, Cree XP-L V5 SMD-LED mit Platine (10x10mm), 460lm, 6200K, CRI 60 pic2 68466
    Cree XP-L V5 SMD-LED, CRI60, Mit Starplatine, 460lm, 6200K 68465

    Cree XP-L V5 SMD LED, CRI60

    $6.00 - $7.00
    $6.00 - $7.00
    $6.00 - $7.00
    $6.00
    in stock

    With its compact XP footprint of 3.45 mm x 3.45 mm, the XLamp® XP-L LED delivers high lumen values ​​and good efficiency. Thanks to the high OCF v...

    View full details
    $6.00 - $7.00
    $6.00 - $7.00
    $6.00 - $7.00
    $6.00

Cree XHP50 SMD LED 1120lm, 6500K, with star board - Highest performance. Lowest cost.

With the Cree XHP50 SMD LED on the star board, we present you with a powerful light source that combines performance and efficiency.

Unsurpassed in performance and reliability

The Cree XLamp XHP50 sets a new standard for lumen density and reliability thanks to the SC5 Technology platform. Experience twice the luminous efficacy of the XLamp XM-L2, Cree's brightest single-chip LED to date, without increasing the package footprint.

Longer life and higher operating temperatures

Despite its high performance, the XHP50 features an extended lifetime - even at demanding operating temperatures.

Reduced system costs

By using SC5 technology, system costs can be reduced by up to 40%. This results in lower thermal, mechanical and optical costs at the system level.

Features of the Cree XHP50 SMD LED
  • SC5 platform: Latest innovation for highest performance
  • 85° binning: High flexibility in lighting design
  • Low thermal resistance: 1.2°C/W for efficient heat dissipation
  • Wide beam angle: 120° for wide area illumination
  • Reflowable: easy integration into existing systems
Cree - A name you can trust

As a long-standing partner of Cree, we are proud to be one of the first addresses for the high-quality LED products of the renowned manufacturer. Cree's wide range of products includes both individual LEDs and ready-made solutions and products.

Attractive wholesale conditions at LUMITRONIX

For corporate customers, we offer attractive wholesale conditions as well as the development and production of individual LED modules and control systems. Benefit from our more than 20 years of experience and our specialised know-how in the LED sector.

FAQ about the Cree XHP50 SMD LED
  1. What is the advantage of SC5 technology?
    The SC5 technology allows for improved luminosity and reliability while reducing costs.

  2. Can I use the Cree XHP50 SMD LED in any lighting system?
    Yes, thanks to the reflow capability, the LED can be easily integrated into existing systems.

  3. How wide is the beam angle of the LED?
    The LED has a wide beam angle of 120 degrees.
Technical Details
SKU
68483
Brand
Light colour
cold white
Manufacturer code
XHP50D-00-0000-0D00J40CB
Luminous flux (lm)
1120 (lm)
Color temperature (K)
6500 (K)
CRI (Ra)
68
Viewing Angle (°)
120 (°)
Power (W)
8.05 (W)
Voltage (V)
5.75 (V)
Electric Current (mA)
1400 (mA)
Size (L x W x H)
2.1 cm x 1.98 cm x 0.15 cm
Weight
0.002 kg
