Nichia NF0604EFC-V5 COB-LED 2700K, CRI 95+
The Nichia NF0604EFC-V5 COB LED provides warm white light with high color rendering and is suitable for demanding indoor lighting solutions. With 2700 K, CRI 95+ and a compact design, this LED combines efficient performance with very good light quality for professional applications.
The COB LED produces a pleasant, warm light pattern that is particularly suitable for homely and atmospheric lighting. Thanks to the high color rendering, colors are displayed in a natural and differentiated way, making them ideal for applications in shopfitting, hospitality or residential areas.
- Technology: COB LED for homogeneous light distribution
- Color temperature: Warm white with 2700 K
- Color rendering: High CRI 95+
- Luminous flux: Typically 730 lm
- Operating current: Typically 360 mA
- Forward voltage: Typically 17.2 V
- Output: Approx. 6.2 W system output
- Design: Compact 13.5 x 13.5 mm
- Material: Ceramic substrate with silicone
- Integration: Suitable for COB optics
Special features of the Nichia COB LED
The NF0604EFC-V5 is part of a compact COB series developed for efficient and space-saving lighting solutions. COB technology enables uniform light emission and high light density, allowing precise light distributions to be achieved with suitable optics.
Thanks to its design, the LED is particularly suitable for spotlights, downlights and accent lighting. It offers a good balance of luminous flux, efficiency and size.
Light quality with CRI 95+
With a color rendering index of 95+, this COB LED is suitable for applications with high lighting quality requirements. Colors appear more natural and differentiated, with warm shades and reds in particular benefiting visibly.
This is particularly relevant for sales areas, living spaces or decorative lighting where the lighting effect plays an important role.
Technical properties and operation
The LED is typically operated at 360 mA and achieves around 780 lumens. The forward voltage is around 17.2 V. A suitable thermal connection is required for reliable operation.
The ceramic package supports heat dissipation. For optimum service life, the COB should be mounted on a suitable heat sink.
Nichia as an LED manufacturer
Nichia is one of the leading manufacturers in the field of LED technology and is known for its high quality and innovative developments. The company has made a significant contribution to the development of modern LED lighting.
As a distributor, LUMITRONIX offers access to Nichia products with attractive conditions as well as technical support for professional applications. Further information can be found at www.lumitronix.com.
Typical applications
The Nichia NF0604EFC-V5 is suitable for a wide range of lighting applications:
- Living room: Pleasant warm white lighting
- Store: High-quality presentation of goods
- Gastronomy: Atmospheric lighting concept
- Accent lighting: Targeted lighting
- Downlights: Compact recessed solutions
FAQ about this COB LED
- How is the COB LED connected?
The LED is operated with constant current, typically at 360 mA. A suitable LED driver is required.
- Is cooling necessary?
Yes, the COB LED must be mounted on a suitable cooling surface to ensure a stable operating temperature.
- Can the LED be combined with optics?
Yes, it is designed for use with COB reflectors and lenses and enables various light distributions.
- For which applications is CRI 95+ useful?
For applications with high color rendering requirements, e.g. in retail or residential areas.
Nichia NF0604EFC-V5 COB-LED 3000K, CRI 95+
The Nichia NF0604EFC-V5 COB LED in 3000 K provides warm white light with high color rendering and is suitable for demanding indoor lighting. With CRI 95+, it combines pleasant light color with natural color rendering.
At 3000 K, this COB LED produces a warm white, slightly more neutral light compared to 2700 K. It is particularly suitable for applications where a homely atmosphere needs to be combined with good visual comfort.
- Technology: COB LED for uniform light
- Color temperature: Warm white with 3000 K
- Color rendering: High CRI 95+
- Luminous flux: Typically 780 lm
- Operating current: Typically 360 mA
- Forward voltage: Typically 17.2 V
- Output: Approx. 6.2 W
- Design: Compact 13.5 x 13.5 mm
- Material: Ceramic with silicone
- Integration: Suitable for COB optics
COB technology implemented in a compact form
The COB design ensures homogeneous light emission and enables simple integration into compact luminaires. This results in clean light patterns, especially for spotlights and downlights.
3000 K for versatile applications
The 3000 K light color offers a good compromise between a warm atmosphere and functional lighting. It is often used in living spaces, offices and retail areas.
Technology and operation
The LED is operated with constant current. Suitable cooling is required for stable performance. The ceramic package supports heat dissipation.
Manufacturer Nichia
Nichia stands for high-quality LED technology and continuous further development in the lighting sector.
FAQ about this COB LED
- Is the LED dimmable?
Yes, with a suitable dimmable constant current driver.
- What cooling is required?
Mounting on a heat sink or metal core PCB is required.
- For which applications is 3000 K suitable?
For living spaces, stores and work areas with pleasant light.
Nichia NF0604EFC-V5 COB-LED 4000K, CRI 95+
The Nichia NF0604EFC-V5 COB LED in 4000 K provides neutral white light with high color rendering and is suitable for functional lighting with natural color rendering.
At 4000 K, this COB LED produces a neutral white light that is well suited to working environments and functional lighting. The high color rendering ensures clear and realistic color perception.
- Technology: COB for a uniform light pattern
- Color temperature: Neutral white 4000 K
- Color rendering: CRI 95+
- Luminous flux: Typically 820 lm
- Operating current: Typically 360 mA
- Forward voltage: Typically 17.2 V
- Output: Approx. 6.2 W
- Design: 13.5 x 13.5 mm
- Material: Ceramic substrate
- Integration: For reflectors and lenses
Neutral white for precise work
4000 K is a frequently used light color for workplaces, offices and technical applications. It offers good visibility without appearing too cool.
High color rendering
With CRI 95+, colors are displayed true to life. This is important for presentation, design and visual control.
Technical integration
The COB LED requires a constant power source and suitable cooling. The package is designed for professional applications.
Manufacturer Nichia
Nichia is an established manufacturer with a focus on high-quality LED products.
FAQ about this COB LED
- Is the LED suitable for offices?
Yes, 4000 K is ideal for working environments.
- Can it be used with optics?
Yes, it is compatible with COB optics.
- What power source is required?
A constant current driver with approx. 360 mA.
Nichia NF0604EFC-V5 COB-LED 5000K, CRI 95+
The Nichia NF0604EFC-V5 COB LED in 5000 K provides neutral white light with high color rendering and is suitable for applications with high visual clarity.
At 5000 K, this COB LED produces a light similar to daylight. It is suitable for applications where high concentration, detail recognition and clear visibility are required.
- Technology: COB for uniform light source
- Color temperature: 5000 K
- Color rendering: CRI 95+
- Luminous flux: Typically 840 lm
- Operating current: Typically 360 mA
- Forward voltage: Typically 17.2 V
- Output: Approx. 6.2 W
- Design: 13.5 x 13.5 mm
- Material: Ceramic package
- Integration: For precise lighting systems
Illumination similar to daylight
5000 K corresponds to a cool, clear light. It is often used in workshops, medical areas or industrial applications.
High level of detail recognition
The combination of high color temperature and CRI 95+ enables very good detail perception and color differentiation.
Technical information
A constant current driver is required for operation. Sufficient cooling is crucial for the service life.
Manufacturer Nichia
Nichia is known for reliable LED technology and high quality.
FAQ about this COB LED
- For which applications is 5000 K suitable?
For technical, industrial and precision applications.
- Is the LED dimmable?
Yes, with a suitable driver.
- Is cooling required?
Yes, a thermal connection is necessary.
